Product Introduction
HMPVH-32 is a dedicated PV DIN Rail Fuse Holder developed for 1500V DC photovoltaic string combiner boxes, perfectly matched with 10×85mm gPV cylindrical fuse links. As standard 10x85mm Fuse Holder, it adopts high flame-retardant PA66 shell and integrated thick pure copper conductive bracket, specially optimized for long-time unstable DC output of solar modules.
Product Parameter
|
Item |
Professional Specification Data |
|
Full Model |
HMPVH-32 1500VDC Solar PV DIN Rail Fuse Holder |
|
Matching Fuse Size |
10mm Dia × 85mm Length gPV cylindrical fuse link |
|
Applicable Fuse Current Range |
2A ~ 32A full in-stock series |
|
Rated DC Working Voltage |
1500V DC |
|
Matched Max DC Breaking Capacity |
33kA |
|
Optional Poles |
1P single pole (PV dedicated) |
|
Shell Material |
UL94-V0 high flame retardant PA66 engineering plastic |
|
Conductive Parts |
One-piece thickened pure copper strip, ultra-low DC contact resistance |
|
Utilization Matching Category |
gPV (Photovoltaic DC exclusive) |
|
Executive Standard |
EN/IEC60269-6, GB/T 13539.6 |
|
Global Certifications |
CE, ISO9001, RoHS |
|
Mounting Standard |
TH35 standard DIN rail plug-and-play installation |
|
Applicable Wire Cross-Section |
1.5 ~ 35 mm² |
|
Working Environment |
-40℃ ~ +60℃, Pollution Grade 3, Installation Category III, Altitude ≤2000m |
|
Core Application |
1500V DC PV combiner boxes, ground solar farms, rooftop distributed PV, energy storage DC cabinets |
Product Advantage
This 1500V DC Fuse Holder strictly adheres to EN/IEC60269 gPV global photovoltaic safety standard, engineered for high-risk 1500V solar DC circuits with a maximum matched 33kA short-circuit breaking capacity, delivering reliable overcurrent & short-circuit protection to eliminate arc explosion hazards. Equipped with standard TH35 DIN rail quick-clamp design, it allows tool-free mounting and rapid damaged gPV fuse replacement without exposing operators to live high-voltage components, extensively adopted in ground solar farms, rooftop distributed PV arrays and lithium battery energy storage DC power cabinets.
Ultra-Safe DC Specialized PV DIN Rail Fuse Holder
Unlike conventional AC Ceramic Fuse Holders that lack DC arc suppression design, this 10x85mm Fuse Holder adopts customized thick copper elastic conductive framework specially optimized for sustained high-voltage DC loads. The upgraded clamping structure effectively disperses arc heat and blocks thermal accumulation during fault conditions, permanently ruling out cabinet overheating, melting and fire risks under long-term continuous operation.
Standard 10×85mm Safety-Compatible Fuse Base
The standardized internal clamping cavity of this 1500V DC Fuse Holder perfectly fits all 2A–32A gPV safety-certified solar fuse links. Uniform overall mounting dimensions guarantee seamless retrofitting for newly built and renovated 1500V PV stations; no cabinet cutting or hole modification is required, avoiding secondary insulation damage that compromises circuit safety.
Production Process & Quality Control System
Packaging, Shipping & After-sales Service
Standard Export Packaging: Fuse link is placed inside a separate inner box, then packed in reinforced shockproof outer export carton for ceramic component protection
Professional After-Sales Service: Complete CE, RoHS official test reports provided for customs clearance and overseas project bidding; 1-year full quality warranty for all PV fuse holders, free electrical selection technical guide for Low Voltage Fuse and PV Fuse system matching
FAQ
Q1: Which fuse links match this 10x85mm Fuse Holder?
A1: Only 10×85mm gPV 1500V DC solar fuse links are applicable for this PV DIN Rail Fuse Holder, standard AC fuses cannot be used in this 1500V DC Fuse Holder.
Q2: What maximum DC voltage can this PV DIN Rail Fuse Holder bear?
A2: Rated up to 1500V DC, this 10x85mm Fuse Holder meets all mainstream high-voltage solar string circuit design requirements.
Q3: Does this 1500V DC Fuse Holder need current derating for high-altitude solar farms?
A3: Follow IEC PV standard: derate working current by 0.5% per 100m above 2000m altitude to avoid overheating of the PV DIN Rail Fuse Holder.
Q4: Can this 10x85mm Fuse Holder be retrofitted to old 1500V PV combiner boxes?
A4: Unified DIN rail mounting size of this 1500V DC Fuse Holder, direct installation without cabinet rework for PV station renovation.
