Zhejiang Hongman Electric Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of pv 800v fuse link in China. We are committed to providing high quality customized products made in China with competitive price. Welcome to wholesale bulk cheap pv 800v fuse link from our factory.
Product Introduction
The PV 800V DC Trip Pop-Up Indicator Fuse Link supports tool-free 35mm DIN rail installation and features built-in fuse trip signal design, making it a top pick for solar integrators, combiner box manufacturers and energy storage equipment suppliers aiming to upgrade DC circuit safety and simplify daily inspection of large photovoltaic power stations. In addition, this dedicated photovoltaic ceramic fuse link integrates multiple premium industrial configurations, including 99% high-purity DC arc-extinguishing quartz sand filler, precision pure copper melt strip and integrated pop-up mechanical trip marker, which deliver industry-leading 50kA DC short-circuit breaking capacity and reliable gPV full-range photovoltaic protection performance.
Product Parameter
|
Item |
Professional Specification Data |
|
Full Model Name |
PV 800V DC Trip Pop-Up Indicator Cylindrical Ceramic Fuse Link |
|
Matching Holder |
PV dedicated DIN rail fuse base (1P/2P/3P optional) |
|
Utilization Category |
gPV (Special full-range overload & short-circuit protection for PV DC strings, solar combiner boxes) |
|
Rated DC Voltage |
DC 800V |
|
Rated AC Voltage |
AC 500V / AC 690V |
|
Rated Breaking Capacity |
DC800V: 50kA; AC500V: 100kA; AC690V: 50kA |
|
Complete Current Range |
0.5A ~ 125A (32A/63A/100A/125A full specifications in stock) |
|
Fuse Tube Dimension |
22mm × 58mm high-strength flame retardant ceramic tube |
|
Arc Extinguishing Medium |
99% purity high silica quartz sand filler, customized for DC arc suppression |
|
Melt Material |
Precision pure copper fuse strip, low power loss & stable DC conduction |
|
Indicator Feature |
Built-in elastic pop-up mechanical trip marker, the fuse link comes with complete fuse blowing indication function, prominent protrusion after fusing |
|
Executive Standard |
IEC/HD 60269-6, GB/T 13539.6 (Special PV fuse standard) |
|
Global Certifications |
CE, CCC, ISO9001, RoHS environmental certification |
|
Installation Method |
Standard 35mm DIN rail plug-and-play mounting, quick replacement |
|
Core Application Scenarios |
PV DC combiner boxes, string inverters, commercial & industrial energy storage systems, off-grid solar power stations |
Product Advantage
1 Dual Signal Output Structure: Real-Time Remote Monitoring for Smart PV Stations
This premium 800V AC Fuse comes with built-in dual signal transmission module, capable of uploading both circuit on-off position signal and fuse blowout alarm signal to PLC, SCADA and cloud monitoring platforms synchronously. Different from ordinary Solar Fuse Link only equipped with local visual indicator, it realizes unmanned intelligent early warning for medium & large photovoltaic power plants. Once overload, short-circuit or reverse current faults happen, the Solar Fuse Link triggers two-way signal feedback instantly, allowing operation teams to pinpoint faulty PV strings remotely without on-site patrol inspection. The intelligent signal design greatly reduces manual inspection labor and avoids unnecessary full DC array power cut, making this 800V AC Fuse the top high-end selection for smart centralized PV projects.
2 Premium Explosion-Proof Ceramic Core, Stable Long-Term High-Load Operation
Manufactured with high-density high-temperature sintered ceramic tube, this high-grade Solar Fuse Link fully complies with strict IEC 60269-6 photovoltaic safety standard, specially optimized for long fluctuating DC output of solar panels. The thickened explosion-proof shell of the 800V AC Fuse strongly suppresses sustained DC arc expansion and arc leakage inside sealed compact combiner boxes. Adopting integrated tin-plated copper end caps plus oxygen-free pure copper melt, this Solar Fuse Link maintains ultra-low contact resistance under continuous full load up to 125A, zero performance attenuation or thermal aging after years of round-the-clock operation. Superior raw material and precision firing process endow the 800V AC Fuse outstanding anti-aging and explosion-proof performance, far exceeding basic industrial standard requirements for conventional fuses.
3 Integrated Visual Indicator + Remote Signal Dual Protection, Minimize PV Downtime
This high-end Solar Fuse Link combines pop-up visible blowout marker and digital signal transmission function into one unit, building dual-layer fault identification system for PV DC cabinets. For on-site maintenance workers, the prominent pop-up indicator of the 800V AC Fuse supports quick visual fault location without extra testing tools; for back-end intelligent control system, the dedicated signal interface of this Solar Fuse Link sends real-time fault alerts automatically. This dual-mode design perfectly matches high-density miniaturized PV combiner boxes used in large-scale solar farms, solving the core pain point of delayed fault response for ordinary fuses lacking remote signal output, greatly improving overall operation efficiency of the whole PV station.
Production Process & Quality Control System
Ceramic Shell Forming The ceramic body is formed through high-temperature sintering to deliver reliable insulation and explosion-proof performance.
Copper Contact Machining Integrally stamped thickened solid copper blades are electroplated with copper-tin alloy for anti-oxidation, effectively reducing contact resistance.
Fuse Element Assembly Precision fuse strips are fitted with high-purity quartz sand (99% silicon content) to achieve rapid arc extinction.
Finished Product Testing Every single unit undergoes individual testing for breaking capacity, temperature rise and overload fusing performance.
Aging Sampling Inspection Long-term operation under rated current is simulated to eliminate potential overheating risks.
Full-process traceable quality control ensures consistent performance of every fuse link.
Packaging, Shipping & After-sales Service
FAQ
Q1: What current specifications of this fuse link are available for bulk solar project orders?
A1: We provide full range of rated current from 0.5A to 125A, including 16A, 32A, 63A, 100A, 125A, all in sufficient stock for large-scale solar project procurement. Every specification of this Solar Fuse Link retains consistent outer size and complete fuse blowing indication function, unified with standard DIN rail bases for convenient stock management.
Q2: Is the mechanical pop-up fuse blowing indicator resistant to long-term high-temperature cabinet environments?
A2: The pop-up indicator component is made of high-temperature resistant engineering plastic, passing 24h high-temperature aging test under 70℃ ambient temperature. Even after long-term operation inside sealed high-temperature PV combiner boxes, the fuse blowing indication function of this 800V DC Fuse will not fail or jam, maintaining stable visible alarm effect after fusing.
Q3: Can this PV 800V DC fuse link be used in energy storage DC cabinet systems?
A3: Yes. This 800V DC Fuse is compatible with DC energy storage circuits within DC800V voltage range. As a multi-scenario Solar Fuse Link, its 50kA DC breaking capacity can effectively isolate short-circuit surges inside lithium battery energy storage cabinets, and the built-in fuse trip indicator helps maintenance staff quickly locate faulty branches of energy storage systems.
