Product Introduction
This robust 32A PV Fuse Holder is engineered with integrated UL94-V0 flame retardant PA66 monolithic insulation shell and reinforced thick copper elastic clamping assembly, specially upgraded to resist frequent alternating surge currents generated by PV inverter AC output circuits. Fully certified to IEC60269-2 and GB/T 13539 gG international safety norms, the 690V AC Fuse Holder delivers superior short-circuit interruption performance, supporting up to 120kA breaking capacity at AC500V and 50kA at AC690V. Equipped with click-fit TH35 DIN rail structure, this 690V 32A Fuse Holder enables tool-free fuse swapping to avoid accidental live contact during maintenance. It serves as the core safety protection component for small PV AC combiner enclosures, inverter auxiliary control cabinets, UPS power systems and low-power industrial distribution boards.
Product Parameter
|
Item |
Professional Specification Data |
|
Full Model |
HM18B-32 690V AC 10×38mm Solar PV DIN Rail Fuse Holder |
|
Matching Fuse Dimension |
10mm Dia × 38mm Length gG AC ceramic fuse link |
|
Applicable Fuse Current |
0.5A ~ 32A full in-stock range |
|
Rated AC Operating Voltage |
AC300 / 400 / 500 / 690V |
|
Matched Max Breaking Capacity |
AC500V:120kA; AC690V:50kA |
|
Pole Structure |
Single pole PV AC dedicated design |
|
Shell Material |
UL94-V0 high flame retardant PA66 engineering plastic |
|
Conductive Parts |
Integrated thickened elastic pure copper strip, ultra-low AC contact resistance |
|
Utilization Category |
gG (General full-range overcurrent protection) |
|
Executive Standard |
IEC60269-2 |
|
Global Certifications |
CE, ISO9001, RoHS |
|
Mounting Standard |
TH35 DIN rail plug-and-play installation |
|
Applicable Wire Cross-Section |
1.5 ~ 25 mm² |
|
Working Environment |
-40℃ ~ +60℃, Pollution Grade 3, Installation Category III, Altitude ≤2000m |
|
Core Application |
Mini 690V PV AC combiner boxes, inverter AC auxiliary cabinets, UPS, light industrial motor control panels |
Product Advantage
Surge-Resistant Conductive Design for Long-Term Circuit Safety The custom thick elastic copper clamp built into this 690V AC Fuse Holder evenly wraps 10×38 gG ceramic fuse bodies, delivering consistent clamping pressure even under repetitive PV AC surge shocks. It efficiently suppresses abnormal temperature spikes caused by fluctuating solar output loads, eliminating hidden overheating hazards inside cabinets. Meanwhile, the fully enclosed flame-retardant housing of the 32A PV Fuse Holder physically blocks high-temperature short-circuit arcs, stopping arc leakage and lowering fire risks for the whole circuit system of this 690V 32A Fuse Holder.
Full-Range Standardized Safety Compatibility for Retrofit PV Projects This 32A PV Fuse Holder achieves universal safety matching with all 0.5A–32A 10×38 gG AC ceramic fuses, covering the full AC working voltage spectrum up to 690V. The unified DIN rail mounting dimension of the 690V AC Fuse Holder supports one-to-one replacement of outdated fuse bases without cutting or drilling cabinet panels. Avoiding secondary insulation damage during renovation greatly maintains the original safety performance of PV power systems, making the 690V 32A Fuse Holder a reliable safety upgrade solution for aged distributed solar stations.
Production Process & Quality Control System
Ceramic Shell Forming The ceramic body is formed through high-temperature sintering to deliver reliable insulation and explosion-proof performance.
Copper Contact Machining Integrally stamped thickened solid copper blades are electroplated with copper-tin alloy for anti-oxidation, effectively reducing contact resistance.
Fuse Element Assembly Precision fuse strips are fitted with high-purity quartz sand (99% silicon content) to achieve rapid arc extinction.
Finished Product Testing Every single unit undergoes individual testing for breaking capacity, temperature rise and overload fusing performance.
Aging Sampling Inspection Long-term operation under rated current is simulated to eliminate potential overheating risks.
Full-process traceable quality control ensures consistent performance of every fuse link.
Packaging, Shipping & After-sales Service
FAQ
Q1: What gG fuse size matches this 690V AC Fuse Holder exactly?
A1: This 32A PV Fuse Holder is exclusively designed for 10×38mm gG ceramic fuses, other dimensions cannot be installed on the 690V 32A Fuse Holder.
Q2: Can this 690V 32A Fuse Holder be installed inside inverter cabinet bodies?
A2: Yes, the slim structure of the 32A PV Fuse Holder occupies little space, perfectly suitable for internal wiring of 690V PV inverter control cabinets.
Q3: What temperature correction coefficient applies to this 690V AC Fuse Holder above 40℃?
A3: When ambient temperature exceeds 40℃, apply Kt derating coefficient per IEC standard to avoid overload heating of the 690V 32A Fuse Holder.
Q4: Is tool disassembly required to replace fuses on this 32A PV Fuse Holder?
A4: No extra tools needed; the plug-in design of this 690V AC Fuse Holder enables quick fuse removal and replacement.
